Animal Pet Feed Maker Press Mill Floating Catfish Fish Feed Making Production Processing Extruder Pellet Machine
تفاصيل المنتج:
| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | MIKIM |
| إصدار الشهادات: | CE |
| رقم الموديل: | MK-100 / MK-300 |
شروط الدفع والشحن:
| الحد الأدنى لكمية: | 1 |
|---|---|
| الأسعار: | US$1,590.00 - 2,490.00 |
| تفاصيل التغليف: | 140.00 سم * 110.00 سم * 90.00 سم |
| شروط الدفع: | L/C ، D/A ، D/P ، T/T |
| القدرة على العرض: | 30 |
|
معلومات تفصيلية |
|||
| قوة: | 5.5 كيلو واط | يكتب: | الطارد |
|---|---|---|---|
| تطبيق: | إنتاج طعام الحيوانات الأليفة | المواد الغذائية: | اللحوم والفاصوليا والخضروات وهلم جرا |
| يحتاج العامل: | 1 ~ 2 العمال | سمات: | مستمر وتلقائي |
| الجهد االكهربى: | 380 فولت | ميزة: | من السهل الاتصال بجهاز التعبئة |
| اسم الجهاز: | آلة صنع طعام الكلاب الجافة | صيغة: | توفير صيغة مجانا |
| المحركات: | العلامات التجارية الصينية ، Siemens ، ABB | ||
| إبراز: | floating catfish feed extruder machine,pet feed pellet making machine,fish feed production processing extruder,pet feed pellet making machine,fish feed production processing extruder |
||
منتوج وصف
Animal Pet Feed Maker Press Mill Floating Catfish Fish Feed Making Production Processing Extruder Pellet Machine
Product Description
Introduction about the floating fish feed pellet machine:
The raw materials can be wheat, soybean, cake and other leftovers etc.
The final products floating pellets are widely used in frogs, aquatic, ornamental fish, pet feed, fish farmers, small feed mill.
Key Features
- The cutting structure is very advanced with cutter shaft fixed spring to cut to realize. Infinitely speed change; the final output product can be cut freely in different length according to requirement.
- The Screw is made of special wear-resisting No38 chromium aluminum molybdenum after tempering, heating and formed; it's with wear-resisting and long life.
- In order to ensure quality and capacity, there is special pressurization die device and the electric heating devices improve the feed expansion rate.
- The main bearing is from Japanese and Sweden bearing to ensure its safety. The main motor is Y-Series three phrase industrial pure copper motor.
- The floating pellets will float on the water for about 12 hours without spreading. The pellets are no pollution and easy for working members to observe. The materials is health and easy for fish and poultry to absorb. Usually if use floating pellet feed can save 8-15% feed than to use powder feed.
Product Images
Technical Specifications
| Model | DGP40-C | DGP50-C | DGP60-C |
|---|---|---|---|
| Power (KW) | 5.5kw | 7.5+0.4kw | 15+0.4 |
| Capacity (kg/h) | 30-40 | 60-80 | 120-150 |
| Weight(kg) | 350 | 400 | 450 |
| Machine size (mm) | 1350*1030*840 | 1470*1110*850 | 1470*1140*840 |
| Model | Capacity/t/h | Power/kw | Feed power/kw | Diameter/mm | Cutting power/kw | Size(mm) |
|---|---|---|---|---|---|---|
| DGP40-C | 0.03-0.04 | 5.5 | 0.4 | Φ40 | 0.4 | 1350*1030*840 |
| DGP50-C | 0.06-0.08 | 7.5-11 | 0.4 | Φ50 | 0.4 | 1470*1110*850 |
| DGP60-C | 0.12-0.15 | 15 | 0.4 | φ60 | 0.4 | 1470*1140*840 |
| DGP70-B | 0.18-0.2 | 18.5 | 0.4 | φ70 | 0.4 | 1790*1470*940 |
| DGP80-B | 0.2-0.25 | 22 | 0.4 | φ80 | 0.6 | 1850*1470*950 |
| DGP90-B | 0.32-0.35 | 37 | 0.6 | φ90 | 0.8 | 2300*1640*1000 |
| DGP120-B | 0.5-0.6 | 55 | 1.1 | φ120 | 2.2 | 2350*2010*1110 |
| DGP135-B | 0.7-0.8 | 75 | 1.1 | φ133 | 2.2 | 2450*2040*1200 |
| DGP160-B | 1-1.2 | 90 | 1.5 | φ155 | 2.2 | 2550*2100*1300 |
| DGP200-B | 1.8-2.0 | 132 | 1.5 | φ195 | 3.0 | 2650*2240*1400 |
